Refrigerated/Reefer Container

20ft Insulated Container

    ISO Size Type Code: 22HM, 25HM, 42HM, 45HM


    Size: 20ft, 20ft HC, 40ft,40ft HC


    Feature: Insulated and waterproof


    Condition: New and ISO standard


  • As one of the leading container manufacturer and supplier. SMC could provide more than 100 kinds of thermal Insulation products for global customer.


  • Our customers often use the 20ft insulated container as storage for demanding products. For example, it can be used to store temperature-sensitive varnish. The insulation lessens the impact of both heat and cold on the temperature inside the container. If you’re looking for an additional cooling quality, you should check out the 20ft reefer container.

  • 1. Consistently high quality standard of our container equipment through worldwide classification society certificate procedure

    2. Adherence to the latest safety standards, regulations and all relevant ISO norms

Dimensions and Capacities of Insulated Containers:



20ft Insulated Container

Dimension

Millimeter

Feet

External

Length

6,058

20

Width

2,438

8

Height

2,591

8.6

Internal

Length

5,454

17.9

Width

2,288

7.5

Height

2,282

7.47

Door
Opening

Width

2,290

7.53

Height at sill

2,239

7.43

Cargo access height

2,231

7.3

Weight

Kilogram

Pound

Max Gross Weight

30,480

67,200

Tare Weight (Excluding Ref. Unit)

2,600

5,730

Maximum Payload

27,880

61,470

Internal Capacity

Cube Meter

Cube Feet

28.4

1,003

Insulation

Item

Thickness (mm)

Density (kg/m3)

Side

63

45-50

Door

74

50-55

Roof

80

40-45

Floor

82-106

45-50

Corner



40
