Haynes 25 Alloy Rod
Grade: Haynes 25 Alloy
Diameter: 4-200mm or customized
Length: 2000-6000mm or customized
Shape: Round / Square Bar
Shanghai Metal Corporation is a leading Haynes 25 Alloy Bar manufacturer and supplier.
Haynes 25 Alloy is a solid solution strengthened cobalt-chromium-tungsten nickel alloy which combines excellent high temperature strength and oxidation resistance to 2000°F with good resistance to sulfidation, wear and galling. It has good forming characteristics and is capable of being forged, hot worked or cold worked, althoug it does work-harden very rapidly so frequent intermediate annealing treatments are recommend for complex forming operations. Haynes 25 Alloy can also be readily welded by most conventional welding methods using similar composition welding wire (AMS 5796) or coated electrodes (AMS 5797). And it is supplied solution heat treated in the range of 2150-2250°F and rapid air or water quenched to attain optimum properties. Haynes 25 Alloy has many applications in military and commercial gas turbine engine components such as rings, blades and combustion chamber parts.
Our Haynes 25 Alloy is available in Bar (Rounds), Rod, Wire, Sheet, Strip, Forging Stock, Foil, Welding Wire. If you want to know more about our Haynes 25 Alloy Bar price, please feel free to contact us, we will reply you within 24 hours.
|
Chemical composition,% |
||||||||||
|
Element |
Co |
Cr |
Ni |
W |
Mn |
Fe |
Si |
C |
S |
P |
|
Content |
Remainder |
19.00~21.00 |
9.00~11.00 |
14.00~16.00 |
1.00~2.00 |
≤3.00 |
≤1.00 |
0.05~0.15 |
0.03 |
≤0.04 |
|
Typical Mechanical Properties |
|||||
|
Material |
Temperature °F |
Yield Strength |
Tensile Strength |
Elongation (%) |
Hardness HB |
|
Haynes 25 Bar |
RT |
≥800MPa |
≥1000MPa |
≥20 |
HB230~300 |
Packing of Haynes 25 Alloy Bar：
Shanghai Metal Products are packed and labeled according to the regulations and customer's requests. Great care is taken to avoid any damage which might be caused during storage or transportation. In addition, clear labels are tagged on the outside of the packages for easy identification of the product I. D. and quality information.
1) Shanghai Metal Standard
2) Customization
