Cable material

AL-PET PVC Bonded Foil

    Color: Natural,  blue



    COREPaper,  plastic

Shanghai Metal Corporation is a leading AL-PET PVC BONDED FOIL manufacturer and supplier.


AL-PET PVC bonded foil mainly used in outer shielding and three shielding cables, and with good bonding performance with PVC. In the construction of the cable connector, it's easier to be processed and manipulated. The utility model discloses a PET aluminum foil PVC complex film, comprising aluminum foil. Embossing layer is made on the outer surface of the aluminum foil; the embossing layer adheres to a PET plastic layer through the adhesive layer; gloss varnish is arranged on the PET plastic layer; the inner surface of the aluminum foil adheres to the PVC plastic layer through the adhesive layer. The utility model not only can select various color and patterns through a plastic film but also can embody the metal luster and the texture of the aluminum foil; the embossing can be made on the surface of the aluminum foil; the pattern of the composite membrane is richer.


If you want to know more about our aluminium products or AL-PET PVC BONDED FOIL price please feel free to contact us, we will reply you within 24 hours.




Specification of AL-PET PVC Bonded Foil:


PRODUCT CODE

STRUCTURE

THICKNESS(micron)

WEIGHT(g/m2)

YIELD(m2/kg)

ALTV-25

AL9-PET12-VC4

25

47.1

22.31

ALTV-42

AL25-PET12-VC4

42

90.0

11.2

ALTV-57

AL40-PET12-VC4

57

134.0

7.4

ADVANTAGE

ž Save cable installation process

ž Reduce cable installation time

ž No need to replace existing tools



STORAGE

Keep the clean standard stock, away from light direct irradiation, pollution and all kinds of mechanical outside force.



HANDLING

The skilled operator should take or lay the materials gently, carefully to avoid scrap and crash problems.



1: Aluminum Foil

2: Embossing Layer

3: Bonding Layer

4: PET

5: Varnish

6: PVC





Packing of AL-PET PVC Bonded Foil:


2

1

More of AL-PET PVC Bonded Foil:

The above mentioned data property should be only regarded as a general guide to product properties but not as a guarantee. Some of the properties can be changed as a result of our efforts to improve the quality of products. Above mentioned production complies with REACH regulations and pass RoHS certification.
