Thickness: 0.14mm – 3.0mm

Width: 600mm - 1500mm

Coating Weight: AZ30 to AZ185

Product Detail | Technical Information | Packaging | More

Product Detail

Galvalume Steel Coil is also named as Aluzinc Steel Coil, this material is widely used in many fields such as building materials, home appliances, automobiles, environment, machinery, and ships. The surface of the material is covered with aluminum-zinc alloy, which is composed of 55% aluminum, 43.4% zinc and 1.6% silicon solidified at 600 °C. The whole structure is formed by aluminum-iron-silicon-zinc with a state of quaternary crystal.

If you want to know more about Galvalume Steel Coil or Galvalume Steel Coil price please feel free to contact us, we will reply you within 24 hours

1. Standard: JIS3321/ASTM A792M
2. Coating Weight: AZ30 to AZ185
3. Spangle: Regular Spangle.
4. Thickness: 0.14mm – 3.0mm

5. Width: 600mm - 1500mm
6. Length: according to the customer's request
7. Coil ID: 508/610mm
8. Coil weight: according to the customer's request

1. Composed of 55% Aluminum, 43.4% Zinc and 1.6% Silicon.

2. Formable, weldable and paintable.

3. Corrosion resistance in the most atmospheric conditions. This is achieved through the combination of the sacrificial protection of the zinc and the barrier protection of the aluminum.

4. Coating out-performs galvanized coating from 2-6 times than hot dip galvanized steel.

Roofing
Structural sections
Composite panels
Air duct
Computer casing
Electric appliance: washing machine, refrigerators, toaster, microwave, etc.

Steel Type & Grade

Steel Type	AS1397-2001	EN10215-1995	ASTM A792M-02	JIS G3312:1998	ISO9364-2001
Steel for cold forming and Deep drawing application	G2+AZ	DX51D+AZ	CS type B,type C	SGLCC	1
Steel for cold forming and Deep drawing application	G32+AZ	DX52D+AZ	DS	SGLCD	2
Structural steel	G250+AZ	S250GD+AZ	255	-	250
	G300+AZ	-	-	-	-
	G350+AZ	S350GD+AZ	345Class 1	SGLC490	350
	G550+AZ	S550GD+AZ	550	SGLC570	550

Surface Treatment

Surface treatment	Feature
Chromated	Minimize the chance of humid-storage staining forms a dark gray surface discoloration on the surface
Chromated	Retain the bright metallic luster for a long period
Oil	Minimize the tendency for humid-storage stain
Chemical treatment and oil	The chemical treatment provides very good protection against humid-storage staining,while the oil provides lubricity for operations
Dry	Must be transported and stored with special precautions to preserve low-humidity conditions
Anti-finger print	Minimize the chance of humid-storage staining forms a dark gray surface discoloration on the surface

Features of Galvalume Steel Coil:

1) Composed of 55% aluminum, 43.5% zinc and 1.5% silicon

2) Formable, weldable and paintable

3) Corrosion resistance in the most atmospheric conditions. This is achieved through the combination of the sacrificial protection of the zinc and the barrier protection of the aluminum.

4) Coating out-performs galvanized coating from 2-6 times than hot dip galvanized steel

Packaging of Galvalume Steel Coil - Aluzinc Steel Coil

Shanghai Metal Products are packed and labeled according to the regulations and customer's requests. Great care is taken to avoid any damage which might be caused during storage or transportation. In addition, clear labels are tagged on the outside of the packages for easy identification of the product I. D. and quality information.

1) Shanghai Metal Standard

2) Customization

Applications of Galvalume Steel Coil - Aluzinc Steel Coil:

1) Construction: roofing, cladding, structural sections, composite panels, etc.

2) Electric appliance: washing machine, refrigerators, toaster, microwave, etc.

3) Others: air duct, lighting, computer casing, etc.
