Impact Resistant Glass
Thickness: 6mm - 60mm
Standard: EN 356, ANSI Z97.1, GA 165-2016, UL 972, UL 752, JIS R 3205
Grade: P1A-P5A, P6B-P8B, Class A, Class B, Levels 1-8
Shanghai Metal Corporation is a professional manufacturer and supplier of Impact-resistant glass with high quality and reasonable price.
Impact-resistant glass, also known as anti-shatter or safety glass, is specifically engineered to withstand strong impacts and prevent breakage or penetration. It is commonly used in environments where safety, durability, and protection are essential. This type of glass is typically composed of multiple layers, including a special inter layer (such as PVB or SGP), which holds the glass together even when shattered.
If you want to know more about Impact-resistant glass price please feel free to contact us, we will reply you within 24 hours.
Technical Information of Impact Resistant Glass:
|
Grade |
Impact Type |
Drop Weight |
Drop Height |
Impact Energy |
Glass Structure |
Maximum Size |
|
IR-1 |
Steel Ball Impact (Pendulum Test) |
4.11 |
1.5 |
~60 |
3mm + 0.38 PVB + 3mm |
1500mm × 3600mm |
|
IR-2 |
Steel Ball Impact (Pendulum Test) |
4.11 |
3 |
~120 |
4mm + 0.76 PVB + 4mm |
1500mm × 3600mm |
|
IR-3 |
Manual Attack |
Axe – 30 strikes |
N/A |
N/A |
5mm + 1.52 PVB + 5mm |
1500mm × 3600mm |
|
IR-4 |
Manual Attack |
Axe – 70 strikes |
N/A |
N/A |
6mm + 1.52 PVB + 6mm |
1500mm × 3600mm |
|
IR-5 |
Heavy Object Impact |
9kg |
1.5 |
~132 |
8mm + 1.52 PVB + 8mm |
Customizable |
Packaging of Impact Resistant Glass:
Packaging details for Impact-resistant glass typically involve specialized handling and protection to ensure the safety and integrity of the glass during transportation and storage.
Crating or Palletizing: Impact-resistant glass panels are often packaged in sturdy wooden crates or pallets to provide structural support and prevent damage during handling and transit. The crates or pallets are designed to securely hold the glass panels in place and minimize the risk of shifting or impact.
Protective Wrapping: Each impact-resistant glass panel may be individually wrapped in protective materials, such as foam or bubble wrap, to cushion against impacts and abrasions. This helps to prevent scratches, chips, or other surface damage that could compromise the integrity of the glass.
Corner Protectors: Corner protectors made from foam or plastic may be affixed to the edges of the glass panels to provide additional protection against impacts and prevent chipping or cracking at vulnerable points.
Secure Fastening: The glass panels are securely fastened within the packaging using straps, bands, or other restraints to prevent movement or shifting during transit. This helps to maintain the alignment and integrity of the panels and reduces the risk of breakage.
Labeling and Handling Instructions: Each package is typically labeled with important information, such as the type and size of the glass panels, handling instructions, and safety precautions. This ensures that personnel handling the packages are aware of the contents and can take appropriate precautions to prevent damage.
Customized Packaging Solutions: Depending on the size, shape, and quantity of the glass panels, customized packaging solutions may be required to ensure optimal protection and efficient handling. This could include the use of custom-built crates, foam inserts, or other specialized packaging materials tailored to the specific requirements of the glass panels.
Shanghai Metal Corporation Impact-resistant glass are packed and labeled according to the regulations and customer's requests. Great care is taken to avoid any damage which might be caused during storage or transportation. In addition, clear labels are tagged on the outside of the packages for easy identification of the product ID and quality information.
